Earthing switch 25 kV - Earthing switch

Earthing switch 25 kV
3EGF021884

Material ID	Name	Weight	Dimensions	Switching force contacts	Material contacts	Number of poles	Mechanical endurance class in accordance with EN 50152-2
3EGF021884	Earthing switch 25 kV	27 kg	770x202x911 mm	250 N	Cu-ETP	1	30.000	PDF	Request

Material ID	Name	Nominal voltage	Creepage Path	Rated impulse voltage	Short-duration power-frequency withstand voltage	Rated short-time withstand current
3EGF021884	Earthing switch 25 kV	25 kV	1590 mm	250 kV	95 kV	40 kA	PDF	Request
