Drop bracket double - Drop bracket

Drop Bracket D42 double
3EGF001421

for 2 steady arms with parallel distance of 90 mm and contact wire distance of 40 mm without uplift blocking

Material ID	Name	Ebs	Build Type	Material	Weight	Diameter	Height
3EGF001421	Drop Bracket D42 double	Ebs 05.96.78 A	with terminal lug electrical connection	AC-42100	0,95 kg	42 mm	137 mm	PDF	Request
3EGF001422	Drop Bracket D55 double	Ebs 05.96.78 B	with terminal lug electrical connection	AC-42100	1,32 kg	55 mm	147 mm	PDF	Request
