Clamps

Wire clamp support D55 wire 70
3EGF011739

with protection sleeve: 3EGF002764

Request

Variants

Material ID Name Ebs Build Type Material Weight Diameter Rope Q Rope Diameter
3EGF009140 Wire clamp support D42 wire 50 Ebs 05.93.21A with U-bolt AC-42100 4,96 kg 42 mm 50 mm² 17 mm PDF Request
3EGF011737 Wire clamp support D55 wire 50 Ebs 05.93.21B with U-bolt AC-42100 4,99 kg 55 mm 50 mm² 17 mm PDF Request
3EGF011738 Wire clamp support D42 wire 70 Ebs 05.93.21C with U-bolt AC-42100 4,97 kg 42 mm 70 mm² 17 mm PDF Request
3EGF011739 Wire clamp support D55 wire 70 Ebs 05.93.21D with U-bolt AC-42100 5,02 kg 55 mm 70 mm² 17 mm PDF Request
3EGF011740 Wire clamp support D42 wire 120 Ebs 05.93.21E with U-bolt AC-42100 4,97 kg 42 mm 120 mm² 17 mm PDF Request
3EGF011741 Wire clamp support D55 wire 120 Ebs 05.93.21F with U-bolt AC-42100 5,02 kg 55 mm 120 mm² 17 mm PDF Request
3EGF014606 Wire clamp support D42 wire 150 with U-bolt AC-42100 4,97 kg 42 mm 150 mm² 17 mm PDF Request
3EGF014607 Wire clamp support D55 wire 150 with U-bolt AC-42100 5,02 kg 55 mm 150 mm² PDF Request
